SKU#: 3021
DIN 2183/UNC/UNF Machine Taps
For hand or machine tapping of through or blind holes in ferrous and on-ferrous alloys.
FEATURE:
* Premium High Speed Steel;
* Spiral Points make chips to go to feeding direction, and protect threads surface;
* Suit for threading through holes in all kinds of materials;
* Round Shank With Square Driver for General Application;
* Bright Surface Finish.
SPECIFICATION:
| Size | Overall Length | Thread Length | Model No. |
| 7/16-14UNC | 100 | 24 | 3021-210 |
| 7/16-20UNC | 100 | 20 | 3021-211 |
| 1/2-13UNC | 110 | 29 | 3021-212 |
| 1/2-20UNF | 100 | 22 | 3021-213 |
| 9/16-12UNC | 110 | 30 | 3021-214 |
| 9/16-18UNF | 100 | 22 | 3021-215 |
| 5/8-11UNC | 110 | 32 | 3021-216 |
| 5/8-18UNF | 100 | 22 | 3021-217 |
| 3/4-10UNC | 125 | 34 | 3021-218 |
| 3/4-16UNF | 110 | 25 | 3021-219 |
| 7/8-9UNC | 140 | 34 | 3021-220 |
| 7/8-14UNF | 125 | 25 | 3021-221 |
| 1-8UNC | 160 | 38 | 3021-222 |
| 1-12UNF | 125 | 25 | 3021-223 |
